Oscon Precisions Pvt. Ltd. is your premier destination for precision machining solutions. Our cutting-edge machine shop is fully equipped to deliver exceptional accuracy and expertise in crafting intricate and complex parts. With capabilities extending to components as small as 2mm x 2mm x 2mm in size to huge components as big as 700mm x 500mm x 500mm in size, we consistently achieve tolerances within an impressive range of 7 microns. Trust us to provide top-quality, finely engineered parts that meet the most demanding specifications and industry standards. Experience precision in excellence with Oscon Precisions Pvt. Ltd. today.

Machining Capability

Development & Production of machined products made of Bar stock, Casting & Forging.
High accuracy machined components for the finest engineering applications.
Machining of Ferrous & Non-Ferrous Materials like Carbon, Brass, Stainless & Mild Steel, Aluminium alloys & Copper alloys.
Machining of Hardened Steel up-to 50 HRC.
Machining of Investment Casting, Sand Casting as well as Shell Moulding casting.
Grinding external & internal up-to precision levels of 7 um.
Services for heat treatments, plating, coatings, polishing and nitriding.

Machineries	No. of Machines	Capacity
CNC Turning Center Make: LMW	6	Max. Turning Diameter - 320mm Max. Turning Length – 310mm Swing over bed – 540mm High precision: Accuracy up to 10 microns.
CNC Turning Center Make: Global	12	Max. Turning Diameter - 120mm Max. Turning Length – 200mm Swing Over Bed – 320mm High Precision: Accuracy up to 10 microns
Vertical Machining Center with 4th Axis Make: LMW	2	Travel Dimensions in XYZ direction: 1000mm x 600mm x 600mm High weight capacity up to 800kg High spindle speed: 12000 rpm High precision: Accuracy up to 5 microns
Vertical Machining Center Make: Global	2	Travel Dimensions in XYZ direction: 400mm x 300mm x 300mm High weight capacity up to 200kg High precision: Accuracy up to 10 microns
Vertical Machining Center Make: Mazak	1	Travel Dimensions in XYZ direction: 762mm x 410mm x 510mm High weight capacity up to 700kg High spindle speed: 12000 rpm Ultra-High precision: Accuracy up to 3 microns
CNC Electrical Discharge Machining Make: Electronica	2	Work table size: 550mm x 350mm ZNC Controller: 35 + 2 Amps X, Y & Z axes DRO built-in
CNC Wire EDM Make: Electronica	2	Work table size: 900mm x 480mm Max. work piece weight: 1000kg Max. JOG speed: 900 mm/min
Surface Grinder	1	Working Surface of the Table: 750mm x 300mm
Centreless Grinding Machine	1	Standard grinding range (dia.): Ø1~Ø40 mm
Pillar Drill	4	Drill capacity: 2mm to 25mm
Hot Forging Press	1	Capacity: 75 ton
Metal Stamping Press	12	Capacity: 10 ton to 65 ton
Hydraulic press	1	Capacity: 20 ton
Boring SPM	2	Drill capacity: 1mm to 5mm
DRO Drill/Mill	1	For die applications
Ultrasonic Cleaning Machine	1	For cleaning

OUR CORE STRENGTH

At Oscon Precisions, we pride ourselves on delivering precision-engineered machined components and assemblies to clients worldwide. Our core strengths include:

Machining Centers: Achieving accuracy up to 10 microns
Turning Centers: Precision up to 10 microns
Grinding Capabilities: Surface and centerless grinding up to 2 microns
Discharge Machining: Highly precise machining for intricate sections
PPAP Level 3 Compliance: Ensuring top-notch production part approval processes

Why Choose Oscon Precisions Pvt. Ltd.?

Quality Assurance: Raw material is sourced from certified mills and foundries with international standards.
Customization: Tailored to meet specific customer requirements.
Compliance: RoHS and REACH compliant for environmentally conscious projects.
Expertise: Years of industry experience and support.
Global Supply Chain: Competitive pricing and reliable delivery of engineered components.
Versatile Manufacturing: Efficient production for low, medium, and high-volume parts.
Discover how Oscon Precisions Pvt. Ltd. can elevate your manufacturing needs with unparalleled precision and flexibility.

Explore our materials and see why Oscon Precisions Pvt. Ltd. is the preferred choice for certified raw materials. Contact us today to discuss your needs.

Material Portfolio

Steel
We offer all grades including: 1018, 1020, 1040, 1045, 12L14, En1A, 1141, 1144, S235, S355, 4140, 4340, 8620, 20MnCr5, 16MnCr5, 11SMnPb30, 20MnV6, 65-45-12

Aluminium
Our aluminium offerings include: Al 6061 T6, Al 6082 T6, AI 7075 T6, AI 2014, AI 2024

Other Materials
We also provide a variety of other materials such as: Brass, Bronze, Copper, Plastics

Stainless Steel
Our stainless-steel range includes: AISI 304/304 L, AISI 303, AISI 316/316 L, AISI 321, AISI 316 Ti, Monel 400 & 500, Hastelloy C20, Inconel 625, 718, 17-4 PH, 15-5 PH, 6Al-4V, CP Grades, AISI 400 Series, Nitronic 50 & 60, Other Ferritic, Martensitic, Duplex Alloys

At Oscon Precisions Pvt. Ltd., we're dedicated to delivering top-notch precision manufacturing solutions tailored to your diverse needs. With cutting-edge technology and a relentless commitment to excellence, we also provide other services to our clients from our list approved suppliers so as to satisfy our clients’ needs with a single point of coordination.

Our Casting Capabilities

High Pressure Die Casting
Materials: All Grades of Aluminium and Zinc.
Maximum Weight: Up to 4 Kg

Investment Casting
Materials: Carbon Steel, Stainless Steel, Brass, Bronze.
Maximum Weight: Up to 50 Kg

Gravity Die Casting
Materials: All Grades of Aluminium.
Maximum Weight: Up to 25 Kg

Our Forging Capabilities

Forging Techniques and Material Grades
Close Die Forging: Carbon Steel, Stainless Steel, Alloy Steel, Aluminium, Brass, etc.
Upset Forging: Carbon Steel, Stainless Steel
Press Forging: Carbon Steel, Stainless Steel Ring Forging: Carbon Steel, Stainless Steel
Ring Forging: Carbon Steel, Stainless Steel

At Oscon Precisions Pvt. Ltd., we offer a wide range of value-added finishes to enhance the performance and durability of our products as per customer’s requirements:
